MC14067B: Analog Multiplexers/Demultiplexers

Datasheet: Analog Multiplexers/Demultiplexers Rev. 6 (178.0kB)

»信頼性データを表示する »材料組成を表示 »製品変更通知 (8)

The MC14067 multiplexer/demultiplexer is a digitally controlled analog switch featuring low ON resistance and very low leakage current. This device can be used in either digital or analog applications.

The MC14067 is a 16-channel multiplexer/demultiplexer with an inhibit and four binary control inputs A, B, C, and D. These control inputs select 1-of-16 channels by turning ON the appropriate analog switch (see MC14067 truth table.)

特長
Low OFF Leakage Current
Matched Channel Resistance
Low Quiescent Power Consumption
Low Crosstalk Between Channels
Wide Operating Voltage Range: 3 to 18 V
Low Noise
Pin for Pin Replacement for CD4067B
Pb-Free Packages are Available*

技術情報
データシート (1)	パッケージ図 (1)
