The FAN49103 evaluation board is a compact circuit for evaluating onsemi’s FAN49103 Buck-Boost regulator in a 20-bump Wafer-Level Chip-Scale Package (WLCSP).
The board includes a connector for I2C communication.
The board also features footprints to accommodate additional input/output capacitors and probe access points to all key circuit nodes so that electrical characteristics can be measured.
Note: This evaluation board can be used with PICPODEVK evaluation kit.
