ONA10IVGEVB: 16 Watt Digital Input Class-D Audio Amplifier with Speaker Sense Digital Output

The ONA10IV is a digital input, mono Class−D audio amplifier with real time, integrated current and voltage sensing of the loudspeaker it’s driving. This sense data is transmitted to the host via a dedicated digital output. The ONA10IV can be directly connected to a 2−cell (2S) or 3−cell (3S) battery and offers a fast automatic gain control (AGC) for brownout protection that can react within 10[1]μs. A separate single-wire bus (MAGC) can be used to automatically synchronize gain changes across multiple ONA10IV instantiations during a brownout protection event. Device-configurable I2C slave addressing allows up to eight devices to share the same digital audio interface bus.
製品 状態 Compliance 簡単な説明 使用パーツ アクション
16 Watt Digital Input Class-D Audio Amplifier with Speaker Sense Digital Output
Avnet (2020-08-19) : 2
タイプ ドキュメント・タイトル ドキュメント ID/サイズ 修正
Eval Board: BOM ONA10IVGEVB Bill of Materials (ROHS Compliant) ONA10IVGEVB_BOM_ROHS - 133 KB  0
Eval Board: Schematic ONA10IVGEVB Schematic ONA10IVGEVB_SCHEMATIC - 212 KB  0
Eval Board: Gerber ONA10IVGEVB Gerber Layout Files (Zip Format) ONA10IVGEVB_GERBER - 1735 KB  0
Design & Development Tools ONA10IVGEVB Design ONA10IVGEVB_DESIGN - 1028 KB  0
Design & Development Tools ONA10IVGEVB Assembly ONA10IVGEVB_ASSEMBLY - 663 KB  0
